Description
Engine
Engine Style : Horizontal
Engine Type : 4-Cycle OHV
Cylinders : 1
Cooling System : Air
Dry Weight : 45 Lbs
CC : 254 CCs
Max Torque : 12.5 Lbs
Cylinder Bore Type : Cast Iron
Bore : 2.99 Inches
Stroke : 2.2 Inches
Compression Ratio : 8:1
Systems
Charging System : 60W AC Only Amps
Starting System : 120-Volt Electric Start w/ Recoil Backup
Ignition System : Electronic Spark
Lubrication
Lubrication : Splash
Oil Capacity : 20 oz
Intake/Exhaust
Fuel : Gas
Carburetor : Float
Muffler : Included
Fuel Tank Size : 0.71 Gallons
Fuel Tank : Included
Crankshaft
Crankshaft Rotation Direction : Counterclockwise
Shaft Size : 1" x 2.767" Inch
Crankshaft Diameter : 1"
Crankshaft Length : 2.767"
Crankshaft End Tapped Size : 3/8"-24
Crankshaft Keyway Width : 3/16" Inches
Overview
Weight : 45 Pounds
Consumer Warranty : 2 Years
Commercial Warranty : 1 Year
Power Type : Gas
