CH395-3102SP
Model |
Command PRO® CH395 |
J1940 Power hp(kW) 1 | 9.5 (7.1) |
Displacement cu in (cc) | 16.9 (277) |
Bore in (mm) | 3.1 (78) |
Stroke in (mm) | 2.3 (58) |
Peak Torque lbs. ft (Nm) | 13.9 (18.8) |
Compression Ratio | 8.5:1 |
Dry Weight lbs (kg) | 61.5 (27.8) |
Oil Capacity U.S. quarts (L) | 1.4 (1.3) |
Lubrication | Splash |
Dimensions L x W x H in | 15.9 x 16.8 x 16.7 |
Backpressure Limit 2 | 30 |
J1995 Power hp (kW) 3 | 9.1 (6.8) |
J1995 Rated Speed (RPM) | 4000 |
